Orthodox Tea Processing Machine

Continuous Physical Withering Machine

Chemical Withering:

Moisture reduction at a desired rate.

The objective is to make leaf'flaccid'or'rubbery' which is essential for the subsequent step of processing (maceration) - rolling or crushing action.

Advantages of separate mode of Physical withering:

  1. Savings in space - Withering troughs not required.
  2. Savings in labour - Numbers of workers required for withering 1-2.
  3. Savings in energy - Reduction of power in withering section
  4. Consistent quality of withering.
  5. Automatic spreading of leaf inside both CCW and CPW

Feature:

Ccw Type 4 Mtr. / Each Module Length 1.2 Mtr:

Content Type Width Centre to Centre Distance Between The Two Rollers Holding capacity of Machine at Different leaf Stack Height.
1.2 mtr1.5 mtr1.8 mtr
CCW-12-SSTRAY 4.0 mtr 15.6mtr 10483 kgs 13104 kgs 15724 kgs
CCW-18-SSTRAY 4.0 mtr 22.8 mtr 15321 kgs 19152 kgs 22982 kgs
CCW-24-SSTRAY 4.0 mtr 30.0 mtr 20160 kgs 25200 kgs 30240 kgs
CCW-30-SSTRAY 4.0 mtr 37.2 mtr 24998 kgs 31248 kgs 37497 kgs

Ccw Type 3 Mtr. / Each Module Length 1.2 Mtr:

Content Type Width Centre to Centre Distance Between The Two Rollers Holding capacity of Machine at Different leaf Stack Height.
1.2 mtr1.5 mtr1.8 mtr
CCW-12-SSTRAY/BELT 3.0 mtr 15.6mtr 7862 kgs 9828 kgs 11793 kgs
CCW-18-SSTRAY/BELT 3.0 mtr 22.8 mtr 11491 kgs 14364 kgs 17236 kgs
CCW-24-SSTRAY/ BELT 3.0 mtr 30.0 mtr 15120 kgs 18900 kgs 22680 kgs
CCW-30-SSTRAY/ BELT 3.0 mtr 37.2 mtr 18748 kgs 23436 kgs 28123 kgs

Cpw Type 3 Mtr. / Each Module Length 1.2 Mtr :

Content Type Width Drying Capacity/Hr Physical Withering Time - (Max. Spread Thickness 8") Centre to centre Distance Between the two Rollers
3Hrs4Hrs5Hrs
CPW PES Belt -3Tier 3.0 mtr 170Kgs/ Tea Made 10.8mtr(8P) 13.2mtr(10P) 16.8mtr(13P)
CPW PES Belt -3Tier 3.0 mtr 270Kgs/ Tea Made 15.6mtr(12P) 20.4mtr(16P) 25.2mtr(20P)
CPW PES Belt -3Tier 3.0 mtr 450Kgs/ Tea Made 26.4 mtr(21 P) 34.8 mtr(28P) 43.2 mtr(35P)
CPW PES Belt -3Tier 3.0 mtr 600Kgs/ Tea Made 34.8 mtr(28P) 45.6 mtr(37P) 56.4 mtr(46P)
